Diesel powered mortar transfer and spraying machine. Designed for ease of use and high performance. Compact in size, it assures an efficient application rapidly and faultlessly of interior and/or exterior plastering, shotcrete, self-leveling screed among various other uses.
Engine
:
4S 35,9 KW 2800 Rpm Kubota
Pump Type
Worm Pump 2L75
Pump Pressure
20 Bar.
Max. Aggregates
Max. 12 mm
Dimensions L/W/H
3700 / 1450 / 1250 mm
Standard Weight
905 kg.
Transfer Range
Max. 60. mt Vertical 120 mt. Horizontal
Loading Height
1000 mm
Spiral Type
2L8/1,5L7
Delivery rate Theoritic
0-18 m3/H
Vessel Capacity
220 Lt
Drawbar and Axle
Adjustable Drawbar and Braked Axle
√ As concrete pump to 16 mm
√ Flowscreed
√ Shotcrete
